常用4mhz晶振型号一览表
作者: 扬兴科技 日期:2021-10-20 浏览量:
常用4mhz晶振型号大全,主要罗列出常用的4mhz晶振系列,其中有4mhz插件晶振,4mhz音叉晶振,4mhz贴片晶振,4mhz无源晶
振,4mhz有源晶振等等,为大家提供全方位选型指导。扬兴科技,33年一直专注扎根于晶振领域,全身心投于国产晶振品牌打造。同
时,作为大中华区epson晶振、sitime晶振一级代理商,坚持做正品直销,保障客户权益。
常用4mhz晶振型号大全 |
|||||||||
---|---|---|---|---|---|---|---|---|---|
图片 | 型号 | 类型 | 品牌 | 频率 | 工作温度 | 频差 | 封装尺寸 | 电压/负载 | 规格书下载 |
hc-49us | 无源晶振 | yxc | 4mhz |
-20℃~ 70℃ -40℃~ 85℃ |
±20ppm | 11.5 x 4.5 x 3.68mm | 20pf | ||
hc-49us | 无源晶振 | yxc | 4mhz |
-20℃~ 70℃ -40℃~ 85℃ |
±20ppm | 11.5 x 4.5 x 3.68mm | 15pf | ||
hc-49us | 无源晶振 | yxc | 4mhz |
-20℃~ 70℃ -40℃~ 85℃ |
±10ppm | 11.5 x 4.5 x 3.68mm | 20pf | ||
hc-49smd | 无源晶振 | yxc | 4mhz | -20℃~ 70℃ | ±20ppm | 11.4 x 4.8 x 3.8 mm | 12pf | ||
hc-49smd | 无源晶振 | yxc | 4mhz |
-20℃~ 70℃ -40℃~ 85℃ |
±5ppm | 11.4 x 4.8 x 3.8 mm | 20pf | ||
yso690pr | 有源晶振 | yxc | 4mhz | -40℃~ 85℃ | ±20ppm | 2.5*2.0mm (2520) | 3.3v | ||
yso1212sr | 有源晶振 | yxc | 4mhz | -20℃~ 70℃ | ±20ppm | 12.7x12.7mm | 5v | ||
yso1512sr | 有源晶振 | yxc | 4mhz |
-20℃~ 70℃ -40℃~ 85℃ |
±20ppm | 20.4x12.8mm |
3.3v 5v |
||
yso110tr | 有源晶振 | yxc | 4mhz |
-40℃~ 85℃ -40℃~ 125℃ |
±20ppm | 3.2*2.5mm (3225) | 1.8v~3.3v | ||
yso8008mr | 有源晶振 | yxc | 4mhz |
-20℃~ 70℃ -40℃~ 85℃ |
±20ppm | 7.0*5.0mm (7050) | 1.8v~3.3v | ||
yso680pr | 可编程晶振 | yxc | 4mhz | -40℃~ 85℃ | ±20ppm | 3.2*2.5mm (3225) | 3.3v | ||
sit5001 | 可编程晶振 | sitime | 4mhz | -40℃~ 85℃ | ±50ppm | 5.0*3.2mm (5032) | 3.3v | ||
sg7050can | 有源晶振 | epson | 4mhz | -40℃~ 85℃ | ±50ppm | 7.0*5.0mm (7050) | 5v |
